Rane Sixty-Two (62) Serato-Scratch Live DJ Mixer

Rane Sixty-Two (62) Serato-Scratch Live DJ Mixer

$150.00

Categories: , , .

Product Description

The Sixty-Two is the ultimate plug-and-play package supporting two-deck digital vinyl simulation, software controls, two USB ports for easy DJ transitions, onboard beat effects, software effects insert and all the record and playback channels you need. The Sixty-Two Mixer supports both analog and Digital Vinyl Simulation (DVS) playback. Serato DJ software and a printed manual are included, and the mixer is backwards-compatible with Serato Scratch Live. It includes Rane’s ASIO and Core Audio drivers to use with all the other popular DJ and DAW programs.

Direct control of over 40 Serato DJ or Scratch Live software controls.
Each of the two USB ports supports six stereo record and four stereo playback channels.
Two DJs can share the mixer, each running different software, for seamless set changes.
32-bit floating point audio processing sampled at 48 kHz.
Mic/line input on XLR/TRS jack with gain trim, two-band EQ, Flex FX assign and On/Over controls.
Internal Effects Engine with Filter, Flanger, Phaser, Echo, Robot and Reverb effects.
External analog inserts for analog effects processor and USB Insert for software effects.
USB Aux Input for SP-6 sample playback with HP/LP Filter, Headphone Cue, and Flex FX assign.
Magnetic crossfader and channel faders with reverse and contour controls.

Specifications

Specifications:

Analog Inputs
4 Stereo unbalanced RCA jacks
Phono or Line Level Input

Rear panel switches for each input
Phono Response

RIAA ±1 dB, Gain: 31 dB at 1 kHz
Max Phono Input

126 mV
Max Line Input

4 Vrms
ADCs
24-bit, 48 kHz; Dynamic range 101 dB A-weighted
DACs
24-bit, 48 kHz; Dynamic range 107 dB A-weighted
Digital Signal Processing
48 kHz, 32-bit floating point
USB Audio
Six Stereo Record, Four Stereo Playback
48 kHz, 32-bit floating point
FlexFX Return

Stereo unbalanced 1/4″ TS (tip-sleeve) phone jack
FlexFX Send
Stereo unbalanced 1/4″ TS phone jack
Mic Input
Balanced 1/4″ TRS & XLR combination jack
Tone Controls

2-band, High and Low
Mic-Line level switch

Choose Line to connect wireless receiver
Line Outputs
Frequency Response

20 Hz to 20 kHz ±0.25 dB, Line in to Line out
THD+N

‹0.01 re 0 dBFS, 20 to 20 kHz, 20 kHz BW
Unbalanced jacks (RCA & FlexFX)

Maximum 4 Vrms
Balanced jacks (Main and Booth)

Maximum 8 Vrms
Internal Universal Power Supply
100 to 240 VAC, 50 Hz to 60 Hz, 15 W max
USB Power
Mixer is self-powered
Unit Size
14.25″ x 10.5″ x 4″
(36.2 cm x 26.7 cm x 10.2 cm)
Weight

10 lb (4.3 kg)

Size
7.75″ H x 15″ W x 19.25″ D
(19.7 cm x 38.1 cm x 49 cm)
Weight

14 lb (6.4 kg)

Video

Manual

Rane Sixty Two Manual

Whats Included

1-Rane Sixty Two (62) DJ Mixer
1-USB Cable
1-Power Cable
1-Mixer Case
