Description
The DN-V300 DVD Players are equipped with standard functions of most DVD Players and includes advanced functions required by professional applications, such as Hide OSD, Change Wallpaper, NTSC/PAL Conversion, Auto Play and various Repeat modes.These advanced DVD players are suited for Commercial, Educational or any Public Installation that requires a Professional DVD Player.
Signal system: NTSC/PAL
Usable Disc: DVD Video, DVD-R/RW (DVD Video), Video CD, Music CD, CD-R/RW
(Audio/MP3/JPEG), Picture CD
Video output: Output level: 1 Vp-p (75Ω/ohms)
Output connectors: Pin jack, 1 set
S-Video output: Y output level: 1 Vp-p (75Ω/ohms), C output level: 0.3 Vp-p
Output connector: S connector, 1 set
Component Video output: Y output level: 1 Vp-p (75Ω/ohms),
PB/CB output level 0.7 Vp-p (75Ω/ohms)
PR/CR output level 0.7 Vp-p (75Ω/ohms)
Output connector: Pin jack, 1 set
Audio output: Output level: 2Vrms
2 channel (FL,FR) output connectors: Pin jack, 1 set
Audio output properties:
(1) Frequency response
DVDs (liner PCM) : 4 Hz to 22 kHz (48 kHz sampling)
: 4 Hz to 44 kHz (96 kHz sampling)
CDs : 4 Hz to 20 kHz
(2) S/N ratio
DVDs : 110 dB
CDs : 110 dB
(3) Total harmonic distortion
DVDs : 0.006 %
CDs : 0.004 %
(4) Dynamic range
DVDs : 100 dB
CDs : 95 dB
Digital audio output: Optical digital output : Optical connector, 1 set
Coaxial digital output: Pin jack, 1 set
RS-232C serial port: D-Sub 9 pin (female) (DN-V300 only)
Power supply: AC 230 V, 50 Hz (*1) AC 120 V, 60 Hz (*2)
Power consumption: 19 W (0.9 W standby)
Dimensions: 434 (W) x 80 (H) x 360 (D) mm
Weight: 3.9 kg
