Product Description
The 4-channel 402-VLZ3 audio mixer delivers pure VLZ3 quality in Mackie’s smallest form factor ever, making it ideal when your input counts are low, or when space is at a premium. In a sleek, small package, you get the signature VLZ3 high headroom, low noise design, complete with 2 XDR2 preamps, premium EQ, and modern mix bus architecture, for the best-sounding, mini-est pro mixer on the planet.
Specifications
• Main Mix Noise:
• (20 Hz—20 kHz bandwidth, 1/4″ main out, channels 1—2 gain @ unity, channel EQs flat, stereo-pan button in.
• Main mix knob down, channel level knobs down: —103 dBu
• Main mix knob unity, channel level knobs down: —98 dBu (102 dB Signal to Noise Ratio, ref +4 dBu)
• Main mix knob @ unity, and channel level knobs @ unity: —92 dBu
•
• Total Harmonic Distortion (1 kHz @ 35 dB gain):
• 20 Hz—80 kHz bandwidth <0.005%
• 20 Hz—20 kHz bandwidth <0.003%
•
• Attenuation (Crosstalk):
• (1 kHz relative to 0 dBu, 20 Hz—20 kHz band-
• width, line in, 1⁄4" main out, gain @ unity.)
• Main mix knob down: —70 dBu
• Channel level knob down: —94 dBu
•
• Frequency Response (Mic input to any output.):
• 20 Hz to 50 kHz: +0 dB/—1 dB
• 20 Hz to 90 kHz: +0 dB/—3 dB
•
• Equivalent Input Noise (EIN) (Mic in to main out, max gain.):
• 150 ohm termination: —129.5 dBu , 20 Hz—20 kHz
•
• Common Mode Rejection Ratio (CRMM): 1 kHz: better than —70 dB
•
• Maximum Levels:
• Mic in: +21 dBu
• Tape in: +24 dBu
• All other inputs: +22 dBu
• All outputs: +22 dBu
•
• Impedances:
• Mic in: 3.4 kilohms
• All other inputs: 10 KΩ or greater
• Tape out: 1.0KΩ
• Phones output: 60 ohms
• All other outputs: 120 ohms
•
• EQ:
• High Shelving ±15 dB @ 12 kHz
• Low Shelving ±15 dB @ 80 Hz
•
• Power Consumption: 8 watts
•
• Dimensions (H x W xD): 7.3" x 5.8" x 1.6", (185.5 mm x 146.9 mm x 40.7 mm)
Whats Included
1-Mackie 402 VLZ3 Mixer
1-Power Tranformer with PowerCord
